Scientists shrink lab-grade ultrafast laser on a single chip for making atomic clocks

Researchers at EPFL – Swiss Federal Technology Institute of Lausanne have integrated an ultrafast femtosecond laser onto a photonic chip.
In a major milestone, the tiny laser went toe-to-toe with tabletop models, packing 1.05 nanojoules of energy into fleeting 147-femtosecond bursts.
“For more than twenty years, a high-pulse-energy femtosecond laser on chip was widely regarded as a holy grail of integrated photonics,” said Professor Tobias J. Kippenberg at EPFL.
“Our result shows that it is not only possible, but that it can be achieved with a surprisingly elegant architecture that the integrated-photonics community had overlooked,” added Kippenberg.

Photonic chip milestone
In this work, an ultrafast laser was miniaturized using photonic chips to route light through microscopic waveguides rather than bulky laboratory equipment. These emit incredibly precise light pulses lasting only a few hundred femtoseconds or quadrillionths of a second.
The high-speed lasers are vital for advanced applications like eye surgery, micromachining, and atomic clocks.
The EPFL team has achieved what many in the field considered impossible. They have built the first integrated chip-scale ultrafast laser that matches the raw performance of its giant, tabletop ancestors.
To pull this off, the EPFL team had to rethink how lasers handle light.
Instead of routing electricity through copper wires, photonic chips guide light through microscopic channels called waveguides etched into a wafer. But when you squeeze immense laser power into channels thousands of times thinner than a human hair, the light violently interacts with itself.
In standard laser designs, this structural stress causes the hyper-fast pulses to destabilize and rip themselves apart.
The solution lay in a forgotten, decades-old fiber-laser concept: the Mamyshev oscillator.
Use in GPS and medicine
Operating like a highly selective photon security checkpoint, this design traps light inside a laser cavity between two optical filters tuned to entirely different color spectra.
While weak, chaotic light fails the test and dies out because it cannot pass through both barriers, high-powered pulses behave differently. Inside the tiny channel, intense pulses naturally spread out into a wide range of colors. This allows the light to clear both filters, loop back, and gain power.
“This design is especially attractive because it does not require any component that is difficult to make on this erbium-doped silicon nitride chip,” explained Zheru Qiu, a co-leading author of the paper.
Better yet, the Mamyshev architecture actually thrives on the intense light-to-light interactions that destroy other chip designs.
The implications of folding a 42-centimeter-long laser path into a microscopic spiral are immense.
Interestingly, these photonic chips can be mass-produced on silicon wafers just like computer processors. A single production run can simultaneously yield more than 1,000 completely independent ultrafast lasers.
Manufacturing at this scale will plummet production costs. Kilowatt-level peak powers, once costing tens of thousands of dollars and occupying half a room, could soon be deployed on affordable, handheld devices.
The technology could be used in various fields. In the near future, environmental teams could use pocket-sized sensors to detect microscopic pollutants in real time. Doctors could perform advanced medical diagnostics in remote villages using handheld tools.
Eventually, these tiny lasers will power compact, highly portable atomic clocks—paving the way for next-generation navigation systems that function flawlessly even when completely cut off from satellite GPS.
The study was published in the journal Nature on June 3.
